Excel.xlsx
The default export. Includes up to 10 sheets depending on your extraction results.
| Sheet | Contents |
|---|---|
| IO List | All instruments with 21 data columns |
| Control Loops | Instruments grouped by loop number |
| Summary | Signal type counts and extraction statistics |
| Consistency Report | Cross-drawing issues, if any |
| Audit Trail | Original values vs. Your corrections, if edited |
| IO Module Estimation | PLC module counts for Siemens, Rockwell, or generic |
| Equipment List | Extracted equipment tags, pumps, vessels, exchangers |
| Line List | Extracted pipe line numbers with size and spec |
| Tag Naming Report | Tag naming convention issues, if any |
| Cable Schedule | Pre-populated cable schedule template |
Best for. Client handoff, final review packages, detailed sign-off.
CSV
Comma-separated format compatible with any spreadsheet tool. Formula injection protection included.
Best for. Quick imports into other tools, data processing scripts.
PLCCreator Device IO List
CSV formatted for direct import into PLCCreator. Choose your PLC architecture.
- Single rack, all I/O on one rack
- Single fieldbus, I/O distributed on one fieldbus
- Multiple fieldbuses, I/O across multiple fieldbuses
Best for. Going from P&ID directly to PLC configuration.
JSON
Structured data with all instrument, equipment, and line fields.
Best for. API integrations, downstream automation, custom pipelines.
TIA Portal XML
Siemens GlobalDB block with I/O tags for S7-1200, 1500 controllers. Import directly into TIA Portal.
Best for. Siemens PLC projects.
Rockwell L5X
Studio 5000 importable tags for Allen-Bradley controllers.
Best for. Rockwell, Allen-Bradley PLC projects.
DEXPI XML
ISO 15926-based DEXPI 1.3 format for process industry data exchange.
Best for. Interoperability with DEXPI-compatible engineering tools.
Annotated PDF
Your original drawing with color-coded overlays showing where each instrument, equipment tag, and line number was found. Includes a legend on the first page.
Best for. Visual verification, markup review, client presentations.
How to export
- Complete an extraction and open the Review view
- Click Export for Excel, or More Formats for all 8 options
- For PLCCreator, choose your architecture in the dialog
