Engineering drawings,
read to the tag.
Tagsight reads P&IDs, indexes, schedules, and SAMA logic at the tag level. Answers questions against the set, and outputs the registers a project ships: I/O lists, instrument indexes, loop folders, MOC packages.
Reads ISA-5.1, KKS, IEC 61511, DEXPI, and in-house conventions.
Try one of yours.
Drop a P&ID, instrument index, or schedule. Tagsight reads it in the browser and opens a workspace. Sign in when you want to save the workspace.
What you can ask
Ask a workspace anything against its drawings. Every answer is cited to the source tag. Open a question for the worked result.
What it builds
Project packages, assembled from the drawings already read into the workspace.
Drawing types Tagsight reads
Ten drawing types, read to the tag. Each one lands as a structured table you can open, query, or export.
Export formats
Every read leaves in the format the next tool expects.
| Format | File | Target tool |
|---|---|---|
| Excel workbook | .xlsx | Index and register handoff |
| Comma-separated | .csv | Any database or script |
| Siemens TIA | .xml | TIA Portal hardware import |
| Rockwell L5X | .l5x | Studio 5000 tag import |
| DEXPI | .xml | P&ID data exchange |
| Intergraph SPI | .txt | SmartPlant Instrumentation |
| PDF report | Review and sign-off | |
| JSON | .json | The Tagsight API |
API and MCP
Reach a workspace from your own code, or hand it to an agent.
Every read, tag, and answer in a workspace is reachable over a REST API. GET /drawings/{id} returns a read, POST /query answers a question against the set, and GET /loops/{tag} traces a loop end to end.
Tagsight also runs as an MCP server. An agent works the drawings with the same tools Tagsight Intelligence uses: trace_signal, list_instruments, cross_reference, and generate_io_list.
Standards Tagsight reads
Tagsight reads to the conventions your drawings are drawn to. Tag formats, instrument types, and identifiers are interpreted against the standard families an engineer already works in, so a balloon, a KKS code, or a BACnet object is read as exactly what it is.
Integrations
Tagsight reads from the tools your team already runs. Writes back out in the formats they expect.
Start with one drawing.
Upload a P&ID, index, or schedule. Tagsight reads it to the tag and gives back the registers a project ships: I/O lists, instrument indexes, loop folders, MOC packages.
