Quick start
- Sign up at tagsight.io and verify your email
- Upload a P&ID. Click "Upload" and select your file, PDF, PNG, JPG, or TIFF, max 250MB, up to 200 pages
- Wait for processing, instruments are extracted from each page, typically 1-3 minutes
- Review the results, check extracted instruments, equipment, and lines. Edit any corrections.
- Export, download in any of 8 formats, Excel, CSV, PLCCreator, JSON, TIA Portal, Rockwell L5X, DEXPI, Annotated PDF
What you get
For each P&ID page, Tagsight extracts.
- Instrument tags, tag numbers, signal classification, AI, AO, DI, DO per ISA 5.1, descriptions, confidence scores
- Equipment tags, pumps, vessels, tanks, exchangers, and other equipment identified on the drawing
- Line numbers, pipe line numbers with nominal size and spec code
- Connected equipment, which equipment each instrument is monitoring or controlling
- Valve details, valve type, fail position, and actuator type for valve instruments
Tips for best results
- Vector PDFs produce better results than scanned images
- High resolution scans, 200 plus DPI improve accuracy on scanned drawings
- Standard ISA 5.1 instrument bubbles produce the most reliable results
- Each engineering drawing in your PDF counts once toward your monthly drawing quota, P&ID, SAMA, loop diagram, single-line drawing. Supporting documents, datasheets, instrument indexes, cable schedules, JB schedules, cause-effect matrices, equipment specs and tabular extractions are included on every plan
