Turn any P&ID into the registers a project runs on.
A P&ID carries every instrument, valve, line, and loop a project runs on. Tagsight reads any drawing, in any convention and any drafting era, scanned or vector, into the I/O list, instrument index, equipment list, and line list your team works from.
Three drawings included on a new account.
Nearly every deliverable is already on the drawing.
The I/O list, the instrument index, the equipment and line lists, the loop folders. Each is a different view of what the P&ID already carries. The drawing holds the whole register. The work is getting it off the sheet cleanly, in the convention it was drawn in.
Tagsight reads the sheet and hands back the structured documents, with every row traceable to the page it came from.
From drawing to register.
- 01UploadA P&ID set as PDF, scan, or image.
- 02Read as drawnEvery tag in the convention the sheet uses.
- 03ReviewConfirm each row against the sheet.
- 04RegistersI/O list, index, equipment, lines.
- 05ExportThe format the next system imports.
Every tag, in the convention it was drawn in.
A vector CAD export, a faded scan, and a phone photo of the sheet on the wall all read the same way. So does the convention. ISA 5.1, KKS and RDS-PP, IEC 81346, NORSOK, Dutch NEN, and the in-house letter codes a plant has used since commissioning each come back in the form the sheet prints them.
- ISA 5.1PT-101
- KKS10LAC01CT001
- IEC 81346=H1+R2-B1
- NENAB2WV05
- DINTIR 7001
The register an engineer signs off.
Every row lands on the sheet it came from, where an engineer confirms it, reclassifies it, or adds a tag the list is missing. The exports run on what you confirmed.
- Read in the convention the drawing was authored in
- Every row traceable to its source sheet
- Confirmed against the sheet by an engineer
- Exported to the format the next system imports
The registers a project runs on.
